JuniperNetworks SSG 520M and SSG 550M Security Policy

D. Interfaces

The SSG 520M and 550M provide a number of interfaces:

· The SSG 520M and 550M have four Ethernet autosensing interfaces (RJ-45) (Data

Input, Data Output, Control, Status). These interfaces are network ports. Each port

has two LEDs that indicate port status:

· The right LED indicates the link status. If the LED is on, this means the link is up.

If the LED is off, this means the link is down.

· The left LED indicates the ethernet activity. If the LED is on and is blinking, this

means the port is active (transmitting/receiving data). If the LED is off, this

means the port is inactive

· Console port RJ-45 serial port connector (Data Input, Data Output, Status,

Control). This port allows initial access to the Command Line Interface (CLI).

· Modem port RJ-45 serial port connector. Disabled in FIPS mode.

· Power interface: AC or DC.

· The module has four status LEDs:

· One Power status LED: Illuminates solid green when the power is supplied to the

NetScreen-ISG.

· System Alarm LED: Illuminates red when a critical alarm occurs, such as a

hardware or software failure, or a firewall attack; illuminates amber when a major

alarm occurs, such as "low memory;" is dark when there are no alarms.

· One System status LED: Illuminates blinking green when the module is

operational, or amber when the unit is booting up.

· HA LED: Illuminates green if the unit is the master, amber if the unit is the slave,

and is dark if HA is not configured.

Hardware reset button: After the user follows this sequence--press for 5 seconds,

release for 5 seconds, press again for 5 seconds, and release again for 5

seconds--the device erases all configurations and restores the default factory

settings (Control Input).

The SSG 520M and 550M have six physical interface module (PIM) slots:

The SSG 520M may be configured with up to 2 Enhanced PIMs (EPIMs). The

SSG 550M may be configured ith up to 4 EPIMs.

· PIM options are:

· The three available EPIMs for the SSG 520M and 550M include:

· 1 port 10/100/1000 copper Ethernet EPIM

· 1 Gigabit Ethernet Small Form-factor Pluggable (SFP) EPIM for iber

connectivity

· 4 port 10/100 Ethernet EPIM

· DS3/E3 PIM includes either one physical DS3 or E3 port with integrated DSU.

· Dual-port Synchronous Serial PIM includes 2 physical serial ports.

· Dual-port T1/E1 PIM includes 2 physical T1 or E1 ports with integrated

CSU/DSU.

E. Setting FIPS Mode

By default, the module is in non-FIPS mode on the first power-up.

Prior to placing the device in FIPS mode, the administrator must load the Juniper firmware
