Non-Proprietary Security Policy, Version 0.18
May 25, 2007
Nortel VPN Router 600, 1700, 1750, 2700, and 5000
Page 7 of 23
© 2007 Nortel Networks
This document may be freely reproduced and distributed whole and intact including this copyright notice.
Section
Section Title
Level
8
EMI/EMC
2
9
Self-tests
2
10
Design Assurance
2
11
Mitigation of Other Attacks
N/A
Notice that N/A indicates "Not Applicable". EMI and EMC refer to Electromagnetic Interference and
Electromagnetic Compatibility, respectively.
1.2 Module Interfaces
The VPN Router 600, 1700, 1750, 2700, and 5000 are multi-chip standalone modules that meet overall level 2 FIPS
140-2 requirements. The cryptographic boundary of the VPN Router 600, 1700, 1750, 2700, and 5000 is defined by
the outer case of the modules that encloses the complete set of hardware and firmware components.
The VPN Routers are validated in three configurations as follows:
1.
With no accelerator cards installed. The hardware version number for this configuration is 600, 1700, 1750,
2700, and 5000.
2.
With the Hardware Accelerator card installed in the 1700, 1750, 2700 and 5000 Routers. The hardware
version number for this configuration is 1700, 1750, 2700 and 5000 with DM0011052.
3.
With the Contivity Security Accelerator card installed in the 1750, 2700 and 5000 Routers. The hardware
version number for this configuration is 1750, 2700 and 5000 with DM0011085 and DM0011084.
The firmware version number (5.05_150) is the same for all configurations.
The VPN Routers are designed to be modular. They include a power supply, Dual In-line Memory Module (DIMM)
Random Access Memory (RAM), processors, hard disk, floppy drive and Peripheral Component Interconnect (PCI)
slots. The VPN Routers communicate with their clients via Local Access Network (LAN) and Wide Access
Network (WAN) network interface cards that can be factory installed or field installed. The following network
interface cards are available
1:
Table 2 - Network Interface Cards Available
Factory Installable
Field Installable
Description
DM1004002
DM1011002
10/100 Ethernet Option Card
DM3919002
DM3919001
1000Base-SX Option Card
DM3919003
DM3919004
1000Base-T Option Card
DM3811001
DM3811002
56/64K Channel Service Unit/Data Service Unit (CSU/DSU) PCI Option
Card
DM2111015
DM2111016
Asymmetrical Digital Subscriber Line Annex A (ADSL) Option Card.
DM2111017
DM2111018
Asymmetrical Digital Subscriber Line Annex B (ADSL) Option Card.
DM1519006
DM1519003
ISDN - BRI S/T Option Card
DM1519005
DM1519004
ISDN - BRI U (US/Canada Only - ANSI Standard) Option Card
DM2111013
DM2111014
Half Height Single Port T1/FT1 E1 (G.703) w/CSU/DSU Option Card
1 The option cards are excluded from the security requirements of FIPS 140-2.
