BrocadeŽ NetIronŽ CER 2000 Ethernet Routers and Brocade CES 2000 Routers and Switches
Version 1.0
Brocade Communications Systems, Inc.
10
Brocade CER 2000 series
Firmware
Multi-Service IronWare R05.8.00a
Table 1 CER 2000 Series Firmware Version
SKU
MFG Part Number
Brief Description
BR-CER-2024C-4X-RT-AC
P/N:80-1006530-01
Brocade CER2024C-4XRT includes 24 RJ45 ports of
10/100/1000 Mbps Ethernet with 4 combination
RJ45/SFP Gigabit Ethernet with 4 fixed ports of 10
Gigabit Ethernet SFP+, 500W AC power supply (RPS9)
BR-CER-2024C-4X-RT-DC
P/N:80-1007213-01
Brocade CER2024C-4XRT includes 24 RJ45 ports of
10/100/1000Mbps Ethernet with 4 combination
RJ45/SFP Gigabit Ethernet with 4 fixed ports of 10
Gigabit Ethernet SFP+, 500W DC power supply
(RPS9DC)
BR-CER-2024F-4X-RT-AC
P/N:80-1006529-01
Brocade CER2024F-4XRT includes 24 SFP ports of
100/1000Mbps Ethernet with 4 combination
RJ45/SFP Gigabit Ethernet with 4 fixed ports of 10
Gigabit Ethernet SFP+, 500W AC power supply (RPS9),
BR-CER-2024F-4X-RT-DC
P/N:80-1007212-01
Brocade CER2024F-4XRT includes 24 SFP ports of
100/1000Mbps Ethernet with 4 combination
RJ45/SFP Gigabit Ethernet with 4 fixed ports of 10
Gigabit Ethernet SFP+, 500W DC power supply
(RPS9DC)
Table 2 CER 2000 Series Part Numbers
SKU
MFG Part Number
Brief Description
RPS9
P/N:80-1003868-01
500W AC PWR SUPPLY FOR NI CER/CES SERIES
RPS9DC
P/N:80-1003869-02
500W DC PWR SUPPLY FOR NI CER/CES SERIES
Table 3 CER Power Supply Module Part Numbers
CER Model
Configuration Details
BR-CER-2024C-4X-RT-AC
(P/N: 80-1006530-01)
Base: BR-CER-2024C-4X-RT-AC
Interface Module: None
License: SW-CER-2024-RTUPG (1)
Power Supply: RPS9 (P/N: 80-1003868-01) (1)
BR-CER-2024C-4X-RT-DC
(P/N: 80-1007213-01)
Base: BR-CER-2024C-4X-RT-DC
Interface Module: None
License: SW-CER-2024-RTUPG (1)
Power Supply: RPS9DC (P/N: 80-1003869-02) (1)
BR-CER-2024F-4X-RT-AC
(P/N: 80-1006529-01)
Base: BR-CER-2024F-4X-RT-AC
Interface Module: None
License: SW-CER-2024-RTUPG (1)
Power Supply: RPS9 (P/N: 80-1003868-01) (1)
BR-CER-2024F-4X-RT-DC
(P/N: 80-1007212-01)
Base: BR-CER-2024F-4X-RT-DC
Interface Module: None
License: SW-CER-2024-RTUPG (1)
Power Supply: RPS9DC (P/N: 80-1003869-02) (1)
Table 4 Validated CER 2000 Series Configurations
