Section 2.1
Services
This section describes services which the CM provides.
Service
Description
Role(s)
Keys
&
CSPs
RWX(Read,
Write,eXecute
)
Algorithm(CAVP
Certification
Number)
Method
Band
Lock/Unlock
Block or allow read (decrypt) /
write (encrypt) of user data in
a band. Locking also requires
read/write
locking
to
be
enabled
BandMaster0
...
BandMaster8
N/A
N/A
N/A
SECURITY
PROTOCOL IN(TCG
Set Method Result)
Cryptographic
Erase
Erase
user
data
(in
cryptographic means)
by
changing the data encryption
key
EraseMaster
MEK(s)
W
Hash_DRBG(#895)
SECURITY
PROTOCOL IN(TCG
Erase Method Result)
RKey
X
AES256-CBC(#3537)
Data
read/write(decr
ypt/encrypt)
Encryption / decryption of
unlocked user data to/from
band
None
MEKs
X
AES256-XTS(#3538)
SCSI
READ/WRITE
Commands
Firmware
Download
Enable / Disable firmware
download and load a complete
firmware image, and save it.
If the code passes "Firmware
load test", the device is reset
and will run with the new
code.
SID
PubKey
X
RSASSA-PKCS#-v1_
5(#1818)
SECURITY
PROTOCOL IN(TCG
Set Method Result),
SCSI
WRITE
BUFFER
RandomNumbe
r generation
Provide a random number
generated by the CM
None
Seed
R
Hash_DRBG(#895)
SECURITY
PROTOCOL IN(TCG
Random
Method
Result)
Reset(run
POSTs)
Runs
POSTs
and
delete
CSPs in RAM
None
N/A
N/A
N/A
Power on reset
Set
band
position
and
size
Set the location and size of
the LBA range
BandMaster0
...
BandMaster8
N/A
N/A
N/A
SECURITY
PROTOCOL IN(TCG
Set Method Result)
Set PIN
Setting PIN (authentication
data)
All for their
PIN
RKey
X
AES256-CBC(#3537)
SECURITY
PROTOCOL IN(TCG
Set Method Result)
SHA256(#2916)
Show Status
Report status of the CM
None
N/A
N/A
N/A
SCSI
REQUEST
SENSE
Zeroization
Erase user data in all bands
by
changing
the
data
encryption
key,
initialize
range settings, and reset
PINs for TCG
None1
RKey
X,W
AES256-CBC(#3537)
SECURITY
PROTOCOL IN(TCG
RevertSP
Method
Result)
MEKs
W
Hash_DRBG(#895)
PIN
W
Table 3 FIPS Approved services
Algorithm
CAVP Certification Number
AES256-CBC
#3537
AES256-XTS
#3538
SHA256
#2916
RSASSA-PKCS#1-v1_5
#1818
Hash_DRBG
#895
Table 4 FIPS Approved Algorithms
Algorithm
Description
NDRNG
Software RNG used to seed the approved Hash_DRBG.
Minimum entropy of 8 bits is 7.28.
Table 4-1 Non-FIPS Approved Algorithms
1
Need to input PSID, which is public drive-unique value used for the TCG RevertSP method.
