Brocade DCX-4S and DCX 8510-4 Backbone
Nineteen (19) tamper evident seals are required to complete the physical security requirements total.
Apply fourteen (14) seals to the backbone front side of the chassis.
Figure 12 Brocade DCX-4S and DCX 8510-4 Backbone front side seal locations
