Module Description
The FortiGate-60C, 60D, 80C, FortiWiFi-60C and 60D are multiple chip, standalone
cryptographic modules consisting of production grade components contained in a
physically protected enclosure in accordance with FIPS 140-2 Level 2 requirements.
The modules have a similar appearance and perform the same functions, but have
different numbers and types of network interfaces in order to support different network
configurations:
·
The FortiGate-60C has 8 network interfaces with a status LED for each network
interface (8x 10/100/1000 Base-T).
·
The FortiGate-60D has 10network interfaces with a status LED for each network
interface (10x 10/100/1000 Base-T).
·
The FortiGate-80C has 9 network interfaces with a status LED for each network
interface (6x 10/100 BaseT, 3x 10/100/1000 BaseT)
·
The FortiWiFi-60C has 8 network interfaces with a status LED for each network
interface (8x 10/100/1000 Base-T). The FortiWiFi-60C also includes an IEEE
802.11a/b/g/n compliant WiFi interface with a separate status LED.
·
The FortiWiFi-60D has 10network interfaces with a status LED for each network
interface (10x 10/100/1000 Base-T). The FortiWiFi-60D also includes an IEEE
802.11a/b/g/n compliant WiFi interface with a separate status LED.
The FortiGate-60C/60D and FortiWiFi-60C/60D each have one ARM compatible CPU.
The FortiGate-80C has one x86 compatible CPU.
The modules are 1u desktop devices. The modules have optional rackmount adapters
that allow installation in standard 19" equipment racks.
The modules do not have external ventilation fans.
The validated firmware version is FortiOS 5.0, build0305, 141216.
Figure 1, Figure 2, Figure 3, Figure 4 and Figure 5 are representative of the modules
tested.
