Power Supply and Fan Status LED (Qty. 2)
7. VDX 6740T-24-F, VDX 6740T-24-R, VDX 6740T-48-F, VDX 6740T-48-R, VDX 6740T-64-ALLSW-F, VDX
6740T-64-ALLSW R, VDX6740T-56-1G-R, VDX6740T-56-1G-F
a. Data Port (Qty. 64): Data Input, Data Output, Control Input, Status Output
·
1G/10G SFP+ ports (Qty. 48) supporting both 1G and 10G data rates
Thirty-two of the forty-eight ports are 10G universal ports which can be configured as
Ethernet ports (1G/10G) or Fiber Channel ports (8G/16G)
·
QSFP ports (Qty. 4)
40G QSFP ports can be used as a native 40G Ethernet port or as four 16G Fiber Channel
ports
b. Management Ethernet Ports (Qty. 1): Control Input, Status Output
c. Serial port (Qty. 1): Control Input, Status Output
d. USB (Qty. 1): Data Input, Data Output, Status Output
·
Brocade USB flash device, XBR-DCX-0131
e. Power Supply and Fan Assembly (Qty. 2)
·
Assembly Connectors (Qty. 2): Power Input, Control Input
·
Assembly Status LED (Qty. 2): Status Output
f.
LEDs
·
System Power LED (Qty. 1)
·
System Status LED (Qty. 1)
·
Power Supply and Fan Status LED (Qty. 2)
8. VDX 8770-4 and VDX 8770-8
a. Line card:
·
BR-VDX8770-48X10G-SFPP-1 (48x10G):
10 GbE port (Qty. 48): Data Input, Data Output
LEDs: Status Output
i. Status LED (Qty. 1)
ii. Power LED (Qty. 1)
iii. Status Port LED (Qty. 48)
·
BR-VDX8770-12X40G-QSFP-1 (12x40G):
40 GbE port (Qty. 12): Data Input, Data Output
LEDs: Status Output
i. Status LED (Qty. 1)
ii. Power LED (Qty. 1)
·
Status Port LED (Qty. 12)
·
BR-VDX8770-48X1G-SFP-1:
1 GbE port (Qty. 48): Data Input, Data Output
LEDs: Status Output
i. Status LED (Qty. 1)
ii. Power LED (Qty. 1)
iii. Status Port LED (Qty. 48)
b. Management Module (MM) (half-slot) :
·
USB port (Qty. 1): Data Input, Data Output
