FI 7.4.00a Non-Proprietary Security Policy
Version 0.
5
Brocade Communications Systems, Inc.
Page 6 of 35
1
Introduction
Brocade® ICXTM 6430 and 6450 switches provide enterprise-class stackable LAN switching solutions to meet the
growing demands of campus networks. Designed for small to medium-size enterprises, branch offices, and
distributed campuses, these intelligent, scalable edge switches deliver enterprise-class functionality without
compromising performance and reliability.
2
Overview
The FIPS140-2 validation includes the eight hardware devices presented in Table 2 running the firmware
version presented in Table 1, referred collectively for the remainder of this document as ICX 6430/6450
device (cryptographic module, or simply the module). Each ICX 6430/6450 device is a fixed-port switch, which
is a multi-chip standalone cryptographic module. Four models are available in both the ICX 6430 series and
ICX 6450 series. The power supplies and fan tray assemblies are part of the cryptographic boundary and
cannot be replaced in the field. The cryptographic boundary for each ICX 6430 or ICX 6450 device is
represented by the opaque enclosure (including the power supply, fan tray and bezels) with removable cover.
For each module to operate in a FIPS approved mode of operation, the tamper evident seals, supplied in FIPS
Kit (Part Number: Brocade XBR-000195) must be installed, as defined in Appendix A.
2.1
FastIron Firmware
The ICX 6430 series and ICX 6450 series (listed in Table 2 ICX 6430 and ICX 6450 Switch Family Part
Numbers) run the same firmware version that includes the cryptographic functionality described in Section 4
Table 1 Firmware Version
Firmware Version
FI 7.4.00a
2.2
ICX 6430 and ICX 6450 Series
Table 2 ICX 6430 and ICX 6450 Switch Family Part Numbers
SKU
MFG Part Number
Brief Description
#1
ICX 6430-24
80-1006002-02
24-port 1G Switch, 4 x 1G SFP Uplink/Stacking Ports
#2
ICX 6430-24P
80-1006000-02
24-port 1G Switch PoE+ 390W, 4 x 1G SFP
Uplink/Stacking Ports
#3
ICX 6430-48
80-1006003-02
48-port 1G Switch, 4 x 1G SFP Uplink/Stacking Ports
#4
ICX 6430-48P
80-1006001-02
48-port 1G Switch PoE+ 390W, 4 x 1G SFP
Uplink/Stacking Ports
#5
ICX 6450-24
80-1005997-02
24-port 1G Switch, 2x1G SFP+ (upgradable to 10G) &
2x1G/10G SFP+ Uplink/Stacking Ports
#6
ICX 6450-24P
80-1005996-02
24-port 1G Switch PoE+ 390W, 2x1G SFP+ (upgradable
to 10G) & 2x1G/10G SFP+ Uplink/Stacking Ports
#7
ICX 6450-48
80-1005999-03
48-port 1G Switch, 2x1G SFP+ (upgradable to 10G) &
2x1G/10G SFP+ Uplink/Stacking Ports
#8
ICX 6450-48P
80-1005998-02
48-port 1G Switch PoE+ 780W, 2x1G SFP+ (upgradable
to 10G) & 2x1G/10G SFP+ Uplink/Stacking Ports
#1 to #8
above with
XBR-000195
NA
FIPS Kit containing tamper evident labels to be affixed
to the module per Appendix A: Tamper Label Application
in this document.
