2. Cryptographic Module Specification
This document is the non-proprietary security policy for the Samsung OpenSSL Cryptographic
Module, and was prepared as part of the requirements for conformance to Federal Information
Processing Standard (FIPS) 140-2, Level 1.
The following section describes the module and how it complies with the FIPS 140-2 standard in
each of the required areas.
2.1. Description of Module
The Samsung OpenSSL Cryptographic Module is a software only security level 1 cryptographic
module that provides general-purpose cryptographic services to the applications. The crypto
module runs on an ARM processor.
The following table shows the overview of the security level for each of the eleven sections of the
validation.
Security Component
Security Level
Cryptographic Module Specification
1
Cryptographic Module Ports and Interfaces
1
Roles, Services and Authentication
1
Finite State Model
1
Physical Security
N/A
Operational Environment
1
Cryptographic Key Management
1
EMI/EMC
3
Self Tests
1
Design Assurance
3
Mitigation of Other Attacks
N/A
Table 1: Security Levels
The module has been tested on the following platform:
Module/Implementation
Device
O/S & Ver.
Samsung OpenSSL Cryptographic
Module
(SFOpenSSL1.0.0e-1.1)
Galaxy S3
Android Ice-cream Sandwich 4.0
Table 2: Tested Platform
2.2. Description of FIPS Approved and Non-FIPS Approved Mode
By default, upon initialization, the module performs self-tests and enters the "Non-FIPS" mode.
Whenever the external application requires "FIPS-Approved" mode, it needs to invoke all the self-
tests by calling FIPS_mode_set(FIPS_Mode). Please note that the self tests invoked before entering
FIPS or Non-FIPS mode are described in Section 10.1.
The module can be switched between FIPS-Approved and Non-FIPS mode by invoking the API
FIPS_mode_set() using the following parameters:
FIPS_MODE = 1
