ViaSat, Inc.
EBEM Cryptographic Module Security Policy, 1057314, Rev. 011,
July 7, 2010
15
Figure 5 Tamper Label Location on Expansion Port with ESEM Installed (1 label)
All tamper labels are installed at the factory except the one shown in Figure 5 for the ESEM. In
the case of an EBEM that contains an ESEM (i.e., as in Figure 5), the one (1) tamper label must
be installed by the CO. Prior to installation, the CO is responsible for securing and having
control at all times of any unused seals. Detailed instructions for the ESEM and tamper label
installation are provided in ViaSat, Inc.'s EBEM Password Administrator User Guide and
Software/Firmware Installation Guide, ViaSat document number 1052586, Section 11.
10. Mitigation of Other Attacks Policy
The module has been not designed to mitigate specific attacks outside of the scope of FIPS 140-
2.
Table 7: Mitigation of Other Attacks
Other Attacks
Mitigation Mechanism
Specific Limitations
N/A
N/A
N/A
