Secure Operation of Crypto-J

RSA BSAFE Crypto-J 4.1 Security Policy

3 Secure Operation of Crypto-J

Crypto-J does not require any special configuration to operate in conformance with

FIPS 140-2 requirements. The following guidance must be followed, however, to

achieve a FIPS140 mode of operation.

3.1 Crypto User Guidance

The Crypto User must only use algorithms approved for use in a FIPS 140 mode of

The requirements for using the approved algorithms in a FIPS 140 mode of operation

are as follows:

The bit-length for a DSA key pair must be 1024 bits.

Random Number Generators must be seeded with values of at least 160 bits in

length.

Bit lengths for an RSA1 key pair must be between 1024 and 4096 bits in multiples

of 512.

Bit lengths for the Diffie-Hellman2 key agreement must be between 1024 and

2048 bits. Diffie Hellman shared secret provides between 80 bits and 112 bits of

encryption strength.

Bit lengths for an HMAC key must be one half of the block size.

If RSA key generation is requested in FIPS140 mode, the toolkit always uses the

FIPS140-approved RSA X9.31 key-generation procedure. Key wrapping

methodology provides between 80 and 150 bits of encryption strength.

EC key pairs must have domain parameters from the set of NIST-recommended

named curves (P192, P224, P256, P384, P521, B163, B233, B283, B409, B571,

K163, K233, K283, K409, and K571). The domain parameters can be specified by

name or can be explicitly defined. The module limits possible curves for Dual EC

DRBG to P-256, P-384, and P-521 in accordance with SP 800-90.

EC Diffie-Hellman primitives must use curve domain parameters from the set of

NIST recommended named curves listed above. The domain parameters can be

specified by name, or can be explicitly defined. Using the NIST-recommended

curves, the computed Diffie-Hellman shared secret provides between 80 bits and

256 bits of encryption strength.

When using an Approved RNG to generate keys, the RNG's requested security

strength must be at least as great as the security strength of the key being

generated. For more information on requesting the RNG security strength, see the

Random Number Generation sections of the RSA BSAFE Crypto-J 4.1

Developer's Guide.

1When used for transporting keys and using the minimum allowed modulus size, the minimum strength

of encryption provided is 80 bits.

2Using the minimum allowed modulus size, the minimum strength of encryption provided is 80 bits.
