Press <Enter> three times.

When the "Welcome to the ProxySG Appliance Setup Console" prompt appears, the system is ready for the

first-time network configuration.

The first time configuration sets up the interface number, IP address, IP subnet mask, IP gateway, DNS

server parameters, username, and password.

In addition to configuring the Internet Protocol service, the modules FIPS Mode of operation must also be

enabled (default is disabled). Setting FIPS mode to "enabled" ensures that all security functions used are

FIPS Approved. The module will transition to to the FIPS mode when the Cryptographic Officer enters

"fips-mode enable" command via serial port. The entry of this command causes the device to power cycle

and Zeroize the Master Appliance Key. NOTE: This command is only accepted via serial port.

3.1.3

Management

The Crypto-Officer is able to monitor and configure the module via the web interface (HTTPS over TLS), serial

port, or secure telnet (telnet over TLS). Detailed instructions to monitor and troubleshoot the systems are provided

in Blue Coat® Systems Installation Guides mentioned in the Blue Coat® Systems SG8100 Series Installation Guide.

The Crypto-Officer should monitor the module's status regularly. If any irregular activity is noticed or the module

is consistently reporting errors, then Blue Coat Systems customer support should be contacted.

The module can be taken out of FIPS mode using the secure serial setup console only. A CLI command ("fips-

mode") will allow FIPS mode to be enabled or disabled. To ensure that CPSs are not shared across FIPS Approved

mode and Non-Approved mode, any change to FIPS mode parameter will trigger a zeroization of the Master

Appliance Key and force the module to power cycle. The FIPS mode parameter will not be modified until after the

Master Appliance Key and power-cycle has completed.

3.1.4

Zeroization

At the end of its life cycle or when taking the module out of FIPS mode, the module must be fully zeroized to

protect CSPs. When switching between FIPS mode and non-FIPS mode, the module automatically reboot, zeroizing

all the CSPs. The Crypto-Officer must wait until the module has successfully rebooted in order to verify that

zeroization has completed.

3.2 User Guidance

The User does not have the ability to configure sensitive information on the module, with the exception of their

authentication data. Although the User does not have any ability to modify the configuration of the module, they

should report any irregular activity they notice to the Crypto-Officer.
